13X18-309 - Desert Dry Molecular Sieve Desiccant

Molecular Sieve - Type 13X

Molecular Sieve Type 13X is a modified form of the sodium Zeolite
with a pore diameter of 10 angstroms.
Type 13X is used commercially for general gas drying
and air plant feed purification (simultaneous removal of Hp and CO₂)
It is also used for liquid hydrocarbon
and natural gas sweetening (H₂S and mercaptan removal).
The larger pore size allows for faster absorption of moisture;
however, it is more subject to contamination.

Nominal Pore Size ............................................ 10 angstroms

Type of Crystal Structure ................................. Body Centerd Cubic

Bulk Density ........................................................ 42 lbs/cu. ft.

Equilibrium Water Capacity ............................. 29% wt.

Water Content (as shipped) ............................. 1.5% wt. (max.)

Heat of Absorption (max.) ................................ 1,800 BTU/lb Hp

Specific Heat (approx.) ...................................... 0.23 BTU/lbl°F

Part Number: 13X18-309

Bead Size: 1/8"

Mesh Size: 4X8

Container Size: 309 lbs.

Container Type: Steel Drum
